3-8 Issue 01, 04/05 CL 5
Step 4: Press or to adjust the parameters value.
Step 5: Press
when the parameter is set to the
desired value.
Step 6: Continue selecting other parameters for
modification as outlined in Steps 2 through 5. When
complete with all modifications, press to return to
the measurement display.
3.2.1 Setting Instrument Gain
Instrument gain level is set to either a DEFAULT value
or to a noise-reducing LOW setting. To select the
instrument gain setting:
Step 1: Press
Step 2: Select the GAIN control
Step 3: Press
to activate the control, then or
to adjust the setting.
Step 4: Press when the adjustment is complete.
3.2.2 Setting Update Rate
Measurements are updated at a rate of 4 or 8 Hz, as
selected by the user. To select the measurement
update rate:
Step 1: Press
Step 2: Select the UPDATE RATE control
Step 3: Press to activate the control, then or
to adjust the setting.
Step 4: Press
when the adjustment is complete.
3.2.3 Specifying Nominal Thickness
When the VIEW parameter is set to DIFF/RR%, the
displayed thickness includes two differential values (in
the instruments units and as a percentage) that
represent the variation from user-specified nominal
thickness (Section 4.4). Nominal thickness is also
Setting Up the CL 5 Instrument Calibration
