Locking and Unlocking Instrument Controls
Setting Up the CL 5
 MINIMUM ALARM
 MAXIMUM ALARM
Custom Setups created using instruments equipped
with an optional A-Scan display store the same
parameters as a base-model unit as well as settings
that affect measurement. A full listing of parameter
settings stored in Custom Setup files is found in
Table 3-1.
Table 3-1
CUSTOM SETUP FILE CONTENTS
Custom Setup File Name Nominal Thicknesswhen differential, %RR, or Velocity
mode is selected
Source Setup File Name Minimum Alarm Thickness
Gain Maximum Alarm Thickness
Resolution of Displayed Values Zero Offset
View Mode Velocity
Measurement Mode
Whenever a Standard or Custom Setup file is recalled,
all of the instrument settings revert to those settings
stored in the file. Note that thickness measurements
are part of Data Recorder files (see Chapter 5) and are
not stored in Setup files.
. Note:
UltraMATE can be used to transfer Custom Setup files
to a PC where they are stored. The stored Setup file
can then be downloaded to any CL 5.
