GE CL 5

CL 5 Issue 01, 04/05 7-7
Model Probe Nominal Contact Measuring
Type Freq. Diameter Range
Alpha 2F & CLF5 Fingertip Contact 10 MHz 0.38 in. 0.060 to 10.0 in.
9.5 mm 1.52 to 254 mm
Steel
Alpha DFR-P Plastics, Delay Line 22 MHz 0.30 in. 0.005 to 0.15 in.
7.6 mm 0.13 to 3.8 mm
Plastic
Mini-DFR Thin Range Delay Line 20 MHz 0.19 in. 0.005 to 0.200 in.
4.8 mm 0.13 to 5.1 mm
Steel
CL1P1 Pencil Probe 15 MHz 0.065 or 0.090 in. 0.008 to 0.175 in.
1.7 or 2.3 mm 0.20 to 4.4 mm
Steel
CA211A Standard Contact 5 MHz 0.75 in. 0.060 to 20.0 in.
19.1 mm 1.52 to 508 mm
Steel
Note: Other Probe Models Available upon request
Cl 5 Probe/Transducer Specifications Specifications
