DGP Digital Generator Protection System GE Power Management
2.1 GENERAL 2 CALCULATION OF SETTINGS
2
1407 INST PU 1.00 to 1.99 per unit 1.50
1408 TL7 0 to 9.9 sec. 1.0
1409 RESET 0 to 999 sec. 1
OVERVOLTAGE: 59
1501 TRIP 0000 to 1111 N/A 0000
1502 ALARM 0000 to 1111 N/A 0000
1503 INV PICKUP 100 to 350 de / 100 to 200 f V120
1504 TIME FAC 0.10 to 99.99 sec. 1.00
1505 e CURVE # 1 (Inverse); 2 (Definite Time) N/A 1
1506 de INST PU 100 to 400 V 240
OVER/UNDER FREQUENCY VOLTAGE CUTOFF 81
1601 UVCUTOFF 35 to 99 % 90
UNDERFREQUENCY SETPOINT 1: 81-1U
1701 TRIP 0000 to 1111 N/A 0000
1702 ALARM 0000 to 1111 N/A 0000
1703 SET PNT 40.00 to 65.00 Hz 60.00
1704 TL8 0.1 to 999.9 sec. 2.0
UNDERFREQUENCY SETPOINT 2: 81-2U
1801 TRIP 0000 to 1111 N/A 0000
1802 ALARM 0000 to 1111 N/A 0000
1803 SET PNT 40.00 to 65.00 Hz 60.00
1804 TL9 0.05 to 99.99 sec. 2.00
UNDERFREQUENCY SETPOINT 3: 81-3U
1901 d TRIP 0000 to 1111 N/A 0000
1902 d ALARM 0000 to 1111 N/A 0000
1903 d SET PNT 40.00 to 65.00 Hz 60.00
1904 d TL10 0.05 to 99.99 sec. 2.00
Table 2–1: DGP SYSTEM SETTINGS & RATINGS (Sheet 4 of 7)
SETTING
NUMBER
MNEMONIC RANGE DEFAULT
5 AMP 1 AMP UNITS 5 AMP 1 AMP
c
6HW WR PDWFK WKH V\VWHP SKDVH VHTXHQFH 6HWWLQJ LQIRUPV WKH UHOD\ RI DFWXDO V\VWHP SKDVH VHTXHQFH HLWKHU $%& RU $&% &7
DQG 97 LQSXWV ODEHOHG $ % DQG & RQ WKH '*3 PXVW EH FRQQHFWHG WR V\VWHP SKDVHV $ % DQG & IRU FRUUHFW RSHUDWLRQ
d
6HWWLQJYDOXH QRW DYDLODEOH LQ '*3$%$ PRGHOV
e
6HWWLQJYDOXH QRW DYDLODEOH LQ '*3$$$ PRGHOV
f
6HWWLQJYDOXH QRW DYDLODEOH LQ '*3&$ PRGHOV
.
