GE Power Management DGP Digital Generator Protection System 2-
7
2 CALCULATION OF SETTINGS 2.1 GENERAL
2
UNDERFREQUENCY SETPOINT 1: 81-4U
2001 d TRIP 0000 to 1111 N/A 0000
2002 d ALARM 0000 to 1111 N/A 0000
2003 d SET PNT 40.00 to 65.00 Hz 60.00
2004 d TL11 0.05 to 99.99 sec. 2.00
OVERFREQUENCY SETPOINT 1: 81-1O
2101 TRIP 0000 to 1111 N/A 0000
2102 ALARM 0000 to 1111 N/A 0000
2103 SET PNT 45.00 to 79.99 Hz 60.00
2104 TL15 0.05 to 99.99 sec. 2.00
OVERFREQUENCY SETPOINT 2: 81-2O
2201 TRIP 0000 to 1111 N/A 0000
2202 ALARM 0000 to 1111 N/A 0000
2203 SET PNT 45.00 to 79.99 Hz 60.00
2204 TL16 0.05 to 99.99 sec. 2.00
OVERFREQUENCY SETPOINT 3: 81-3O
2301 df TRIP 0000 to 1111 N/A 0000
2302 df ALARM 0000 to 1111 N/A 0000
2303 df SET PNT 45.00 to 79.99 Hz 60.00
2304 df TL17 0.05 to 99.99 sec. 2.00
OVERFREQUENCY SETPOINT 4: 81-4O
2401 df TRIP 0000 to 1111 N/A 0000
2402 df ALARM 0000 to 1111 N/A 0000
2403 df SET PNT 45.00 to 79.99 Hz 60.00
2404 df TL18 0.05 to 99.99 sec. 2.00
DIGITAL INPUT: DIG INP
2501 SELBKDI1 NO BLK (0); BLK #1-9 (1-9) N/A NO BLK
2502 DI3 TRIP 0000 to 1111 N/A 0000
Table 2–1: DGP SYSTEM SETTINGS & RATINGS (Sheet 5 of 7)
SETTING
NUMBER
MNEMONIC RANGE DEFAULT
5 AMP 1 AMP UNITS 5 AMP 1 AMP
c
6HW WR PDWFK WKH V\VWHP SKDVH VHTXHQFH 6HWWLQJ LQIRUPV WKH UHOD\ RI DFWXDO V\VWHP SKDVH VHTXHQFH HLWKHU $%& RU $&% &7
DQG 97 LQSXWV ODEHOHG $ % DQG & RQ WKH '*3 PXVW EH FRQQHFWHG WR V\VWHP SKDVHV $ % DQG & IRU FRUUHFW RSHUDWLRQ
d
6HWWLQJYDOXH QRW DYDLODEOH LQ '*3$%$ PRGHOV
e
6HWWLQJYDOXH QRW DYDLODEOH LQ '*3$$$ PRGHOV
f
6HWWLQJYDOXH QRW DYDLODEOH LQ '*3&$ PRGHOV
.
