Here some examples for filter combinations on filter switches position 1 and 2:
Pre-selected filters
Jumpers combination JP100 and JP101
Position 1  By-Pass
Position 2  F1
J2 + J4 + J9 + J10
Position 1  F1
Position 2  F2
J1 + J6 + J10
Position 1  F4
Position 2  F3
J8 + J11 + J10
