GE EGR2000

39
Installation Instructions
GAS PIPE AND ELECTRICAL OUTLET LOCATIONS (for models with Sealed Burners)
This area allows for flush range
installation with through-the-wall
connection of pipe stub/shut-off
valve and rear wall 120V outlet.
This area allows for flush range installation
with through-the-floor connection of pipe
stub/shut-off valve.
Shortest connection from hard
pipe stub location to range
hookup.
GAS PIPE AND ELECTRICAL OUTLET LOCATIONS (for models with Standard Twin Burners)
This area allows for flush range installation
with through-the-floor connection of pipe
stub/shut-off valve.
Shortest connection from hard
pipe stub location to range
hookup.
This area allows for flush range
installation with through-the-wall
connection of pipe stub/shut-off
valve and rear wall 120V outlet.
