GE GEH50DEED - Page 52

– 52 –
Lower Element Circuit
LE
UE
DLB
TCO
170°F
T2
NO
NO
NO
COMCOM COM
NC
NC
L1
L2
YELLOW
PINK
VIOLET
T5
(ambient)
BLACK
RED
LOWER ELEMENT
4500W 12.8 Ω ~ 18.75 A
BROWN
BROWN
CT101
K204
K203 K201
1
2
3
4
T5
T2
T3A T3B
T4
EEV
YELLOW
WHITE
BLACK
RED
WHITE
BLUE
ORANGE
YELLOW
RED
GRAY
