GE GEP-09CA User Manual

1.Screw off the drain cover and unplug the water stopper
2.Connect drain-hole with 13mm external diameter PVC
drain hose, into depth of 8mm-10mm .
3.Pull the end of the drain hose to a drain outlet within the
home, or to the outside of the home.
NOTE:
• Drain hose must be installed before unit starts
working.
• The drain hose should be routed so that it cannot be
accidentally accessed during normal use. It should
also be laid as straight as possible, with no sharp
bends that would restrict water flow. The entire drain
hose should also be kept at a level below that of the
drain port.
CONTINUOUS DRAIN IN DEHUMIDIFICATION MODE:
The upper drain port is the best.
Choke Hazard
Keep the drain cover and the water stopper stored
safely, out of the sight and reach of infants and children,
when continuous drainage has been adopted.
ENGLISH
9
10
WARNING

GE GEP-09CA Specifications
