Indoor Unit Installation
Driver
Torque wrench
(17mm,22mm,26mm)
Nipper
Reame r
Hacksaw
Pipe cutter
G as leak age detector or
soap-and-water solution
Hole core drill
Flaring tool
S panner(17,19 and 26mm)
Knife
Measuring tape
Necessary Tools for Installation
Power Source
The electrical power outlet should be located sufficiently close
to the indoor unit, such that the cord-set and plug are not placed
Do NOT extend the power cord for any reason. If the electrical
The electrical power outlet should have sufficient capacity for the
A exclusive brance circuit should be used.
rated input current/power marked on the rating plate.
Selection of the Installation Location
Install on the wall that is sufficiently strong and robust
to support the weight of the Indoor unit.
The installation location should be away from sources
of heat and humidity.
Locate where the connection piping& electrical cable
can be easily connected to the outdoor unit.
Locat e where the drain house outlet will not cause a
Locate where the cooled/heated air can be spread entirely
Locat e close to an accessible power outlet.
Locate more than 1m away from televisions, wireless devices
and fluoresecent lamps.
If the remote control is fixed to a wall, locate it in a location
where the signal is not affected by fluorescent light starting
devices.
Thedistancebetween
the indoor unit and the
floor should be more
than 2m.
These indoor unit models are designed exclusively for use with HFC refrigerant R 410A.
more than
10cm
more than 15cm
more than 10cm
Arrange ment of piping
directions
Rea r left
Le ft
Rear
right
Right
Below
Attention must be paid to
the rising up of drain hose
Please be subject to the actual product purchased,the above picture is just for your reference.
Remot e controller (1)
Mounting plate (1)
Drain hose (1)
Ø 4X 25 S crew
(4)
Plastic cap (4)
Accessory Parts
FOR 09K 12K
FOR 18K
Selection of Pipe
11
Drawing for the installation of indoor units
disturbance on the outside of the wall.
around the room (avoid corners of rooms).
under strain.
power outlet is too far away, it should be relocated by a qualified
electrician in accordance with local codes and regulations.
The air conditioner should always be plugged into itsown
individual electrical outlet having a voltage rating that matches
the rating plate.
Air purifying filter((1)
RISK OF PERSONAL INJURY.
Do not locate the
Indoor Unit in a location where the
airflow is likely to be
channeled directly at people or
animals.
Risk of electric shock. Can cause injury or death.
Ø 4X 12 S crew (2)
24K
