Installation Instructions
CONNECTING AN ELECTRIC DRYER
Before making the electrical connection, turn off the
circuit breaker(s) or remove the dryer’s circuit fuse(s) at
the electrical box. Be sure the dryer cord is unplugged
from the wall. NEVER LEAVE THE ACCESS COVER
OFF THE TERMINAL BLOCK.
TOOLS YOU WILL NEED
Slip-joint pliers
Flat-blade
screwdriver
Phillips
screwdriver
Level
Disconnect power supply before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
- Electrical Shock Hazard
WARNING
MATERIALS YOU WILL NEED
Ŷ
4” dia. metal elbow
Ŷ
3/4” Strain relief
(UL recognized)
Ŷ
4” Duct clamps (2) or
4” spring clamps (2)
Ŷ
Safety glasses
Ŷ
4” dia. metal duct
(recommended)
Ŷ
Gloves
Ŷ
Exhaust hood
Ŷ
Duct tape
Ŷ
4” dia., UL-listed
flexible metal duct
(if needed)
Ŷ
Dryer power cord kit
(not provided with
dryer)
UL rated 120/240V,
30A with 3 or 4 prongs.
Identify the plug type
as per the house
receptacle before
purchasing line cord.
Ŷ
4” Cover Plate
(Kit WE49X22606)
(if needed)
Stacking installations
may require a power
cord up to 6 feet in
length.
To Next Page
