23
The following list of tools and supplies are required for the
completion of this installation:
Tools (not provided)
• Slip Joint Pliers 12" • Knife
• Pipe Wrench 12" • Air Pump
• Adjustable Wrenches • 1/4" Hex Key
• Torpedo Level • Torch with Gas
• Fine Slot Drivers • Snips
• Phillips Drivers: #0, 1 • Robertson Drivers:#1, 2
• Nut Drivers: 5/16, 3/8 • Masonry Drill with 3/8"
Bit
Supplies Required (not provided)
• Copper Pipe • Pen or Pencil
• Ground Wire • Funnel
• Flux and Flux Brush • Hose Clamps
• Solder (lead free) • Suspension Strap
• Assorted Copper
Fittings
• Tie Wraps or Cable Ties
• Plumber Tape or Pipe
Dope (for potable
water)
• 5/8" Hose for Drain
(comply with local
plumbing code)
• 3 Water Shut-o Valves
(same size as install
piping)
• 2' x 2' Patio Stones
(required only for
heated oor)
• Unscented Chlorine
Bleach (Clorox) - 5-6%
or 12%
Tools Supplied with Integrity Test Kit
• Integrity Tester • Housing Wrench
• Cap Wrench • Two Pressure Gauges
• Silicone Lubricant -
DOW CORNING 111
• Digital Air Pressure
Gauge
• Two 1/4" Tubings
Spare Parts (recommended)
• AA Batteries • O-ring
• Inlet Solenoid Valve • Drain Solenoid Valve
• Air Relief Valve • Advanced Plus
Controller
• Stainless Steel Flex
Hose
• 1/4" Mini Ball Valve
with Plug
• 3/4" Inlet/Outlet Fitting • 1/2" Nipple
WARNING: Ball valves are
recommended for use as the bypass, inlet and outlet
valves. Gate valves have a tendency to leak, allowing
unltered water to mix with ltered water. The result
may cause personal injury, sickness and/or death.
System Parts List
UFC 211 and UF 211
• System
(pre-assembled)
• Transformer (120VAC)
• System Base • Advanced Plus
Controller
• Carbon Prelter • Cap Wrench
• Two Stainless Steel Flex Hoses
Inside the bubble bag:
• 1 - Drain Solenoid Valve
(normally closed)
• 2 - 3/4" Inlet/Outlet
Fittings
• 1 - Nylon Elbow • 1 - 1/2" Nipple
• 2 - 1/4" Mini Ball Valves
with Plugs
• 3 - 1/4" x 2-1/2"
Anchors
• 1 - Air Relief Valve • 3 - Shims
• 3 - 3/8" Bolts
Surface Water Kit (optional)
• 1 - External Prelter
Housing
• 1 - 1/4" Mini Ball Valve
with Plug
• 1 - Wall Bracket Kit • 1 - Check Valve
• Mounting Screws • 4 - 1/2" Lag Bolts
• 1 - Inlet Solenoid Valve
(normally open)
• 1 - External Prelter
Cartridge (20- micron
nominal)
Horizontal Mounting Kit (optional)
• 2 - Cast Iron Stands • 1 - Air Relief Valve
• 1 - Metal Support Strap • 2 - Cast Iron Cross
Members
• 1 - Brass 1/2" Elbow • 1 - Brass 1/4" Tee
• 1 - Brass 1/2" Plug • 1 - Foam Gasket
• 1 - PVC 1/2" Nipple at
2" Long
• 1 - Brass 1/2" x 1/4"
Reducer Elbow
• 1 - Polypropylene 1/4"
Closed Nipple
• 1 - Polypropylene 1/2"
Closed Nipple
• 1 - Concrete Floor Bolt • 4 - Wall Mounting Bolts
2-1/2" Long
• 3 - 1/4" x 1" Bolt & Lock
Nut
• 5 - 5/16" x 1-1/4" Bolt &
Lock Nut
