GE IS200ADIIH A Series User Manual

•
••
•
Auxiliary Drive to ISBus Interface Board IS200ADII GEI-100305
16
New Installations
ADII Required Parts
When installing an ADII board in a drive that has not had this board in it previously,
GE kit number 277A8496G01 is required. This kit includes the ADII board, LNPL
cable, DCOM wire, and chassis wire (see Table 15 for individual part numbers).
Note When adding the ADII board in the field, a new 2PL cable assembly will also
be needed. The part number for the 2PL cable assembly differs for different drives.
Refer to Table 16 for the 2PL part number of the applicable drive/frame size.
Table 15. ADII Board New Installation Part Numbers
Part Description Part Number
ADII board Auxiliary drive to ISBus interface board IS200ADIIH_A_ _
2PL Power cable from the power supply board to
the LDCC board and ADII board
See Table 16
LNPL 40-pin ribbon cable to the LDCC board 336A3493AA G01
DCOM wire Common wire from the LDCC board to the
ADII board (runs parallel to the LNPL cable)
336A3438AT G15
CHASSIS wire Ground wire from the ADII board to the
drive's chassis
277A8495G01
Table 16. AcDc2000 Frame Size/Drive 2PL Part Numbers
Frame/Drive Part Number
BM 36B605787ACG06
C 36B605787ACG01
G 36B605787ACG01
M 36B605787ACG06
J 36B605787ACG06
AA 36B605787ACG03
AP 36B605787ACG03
AQ 36B605787ACG06
AT 36B605787ACG06
AS/AW 36B605787ACG08
SilcoMatic 2000 246B235JLG01
IM2000 36B605787ACG03
CV2000 36B605787ACG06
