GE LanPro 11 U - Page 45

GE Digital Energy
g
LanPro
®
5/6/8/10-11U 208-240V input
MANUAL BYPASS SWITCH
INPUT / OUTPUT TERMINALS
BATTERY FUSES
CONTROLS / CIRCUIT BREAKERS
BATTERY PACK CONNECTOR
OPTION SLOTS
RS232 / CONTACT INTERFACE
SUB-D PINNING
NORMAL: POSITION 1
(LOAD ON UPS)
SERVICE: POSITION 2
(LOAD ON BYPASS)
EARTH
CONNECTION
IS ESSENTIAL
UPS UTILITY
STATIC
BYPASS
ON
OFF
1-2 BATTERY
DISCONNECTED
3-4 EMERGENCY
SHUTDOWN
RS232 / CONTACT, SEE BELOW
SNMP CARD OR RELAY CARD
RPA CARD
PARALLEL OPERATION
1 - BATTERY L OW
6 - BYPASS ACTIVE
2 - SERIAL DATA OUT
7 - PLUG & PLAY / RTS
3 - SERIAL DATA IN / UPS SHUTDOWN
8 - MAINS FAILURE
4 - NOT USED
9 - GENERAL ALARM
5 - COMMON
x
y
4 x M8
w
CASTORS
h
d
CONDUIT BOX
CABLE ENTRY
A
B
POSITION A: FIX UPS TO THE FLOOR
POSITION B: LIFT UPS CASTORS FROM THE FLOOR
LEVELLER
z
L1 L2
  
