GE HEALTHCARE VIVID FIVE
D
IRECTION 5341787-100, REVISION 8 BASIC SERVICE MANUAL
6 - 2 Section 6-2 - Monitor Adjustments
Section 6-2
Monitor Adjustments
6-2-1 Adjustments Procedures
To adjust the brightness:
For LOGIQ C3/LC5 Premium: Adjust the LCD monitor’s button, located the right side of the LCD
Monitor.
For LOGIQ C3/LC5 Premium: Adjust the LCD monitor’s button, located the bottom of the LCD Monitor.
To adjust the light:
NOTE: If the left side button of the LCD has the light symbol, the LCD has the lights to light the keyboard.
For LOGIQ C3/C5 Premium: Adjust the left side button of the monitor to turn on/off the light.
Figure 6-52 LCD Monitor
Figure 6-53 Light Adjustment
