Version History P40 Agile P14D, P14N, P94V
8 P40Agile-VH-EN-9
Relay type: Agile P14N, P14D and P94V
Issue
Description of Changes Technical Documentation
· Language translations of all new DDBs and settings are in English apart from French.
The display of the cell[0341][0345][0347][0343] misses a sign minus on Modbus protocol, and the value of new
adding cells can't be taken.
SecAvgMSTA.Volts4.rang.max.f is not configurable.
· The IEC61850 communication disconnect when BRCB with special configuration is Enabled
· Trip elements 5 is missing in fault record of DNP protocol.
· CTS operations when [4609] CTS VN< Inhibit is not satisfied.
· Command "Reset Total Autoreclosures" is missing for P94VR DNP Object 10.
· DNP Binary Input 42 and Binary Input 299 could not be set when DDB 167 "UV Block" is ON.
· Wrong DDB mapping for DA VtpAvgPTOV2.Str.PhsC.
When browsing Fault Record from HMI, Avg O/V Start operates unexpectedly when AVG OVER VOLT protection
is disabled.
FUN number should be 164 instead of 162 for DDB #549 "dv/dt2 StartA/AB" in L & F "IEC60870-5-103" spread
sheet.
· Modbus address of all DDBs in "Alarm status 2" and "Alarm status 3" are incorrect.
· Some menu text mistake in 55A version.
Look & Feel Start Elements, Trip Elements available options, "Fault Record" spread sheet need update.
Data Group Modbus missing, Modbus Number of steps shift from cell [420D] V<3 Function to [4211] V<3
Poledead Inh in Look & Feel.
· Max value 10Hz could not be set to cells f+Df/Dt x Dfreq(x=1 to 9) via Modbus protocol.
The mapping "Measurements/SecMSTA1$MX$AvVAr3$mag$f" was wrong, it should map to the cell [0342]("+3Ph
VAr Fix Dem").
· The new Average voltage protections keep running even if 091D is disabeled
FAULT RECORD Start CN and Trip CN are missing from UI when two stages of average voltage protections are
both enabled in case of three phase faults.
· BRCB - Wrong response when client sets an unknow EntryID value before enable it
· DO sequence error in ICD file
Modbus Start, Data Group Modbus, Modbus Number of steps, Modbus registers are incorrect for Frequency
Protection Stage 9 cells in L&F.
In Unsolicited mode, the measured unsolicited response time is 5s greater than the setting [1B 04] - "Unso
Response" value
· The cell text of these cells[4201][4220][4240][4250] are not consistent with look&feel file.
· The cell [30 11] Dir Char Setting exist in P94VR.
Modbus address error in L&F for cell [03 28] ~ [03 2D]
· Inconsistency between L&F and sw.
There is no translation for these DDB(ordinal:1799-1842) in look & feel file.
· The "ASDU Type" in "Fault Record" that's extracted by Px40VDEW is not consistent with look & feel file.
· The format of Build Date&Time is not correct.
