16
Care and Cleaning
Icemaker
Light bulb
replacement
The icemaker has a light bulb in the top of the
storage bin. To replace it, open the bin door
and follow these instructions:
1. Unplug the icemaker or disconnect power.
2. Remove the 3 screws that hold the cutter
grid cover in place. Reach behind the
control panel and pull the light bulb down.
3. Replace with a 12-volt wedge base-type bulb
(automotive #917). Locate the light bulb
receptacle at the top behind the control
panel. Align the flat edge of the light bulb
with the receptacle and snap the bulb
into place.
4. Replace the cutter grid cover with the
3 screws.
5. Plug in the icemaker or reconnect power.
Vacation
and moving
To shut down the icemaker:
1. Unplug the icemaker or disconnect power.
2. Remove all ice from the storage bin.
3. Shut off the water supply.
4. Remove the 2 screws in the lower access
panel and the 2 screws from the base grille
area of the front panel support. Pull forward
to remove the lower access panel.
5. Disconnect the inlet and outlet lines to
water valve. Allow these lines to drain and
then reconnect to the valve.
6. Replace the lower access panel and screws.
Drain water from water pan by removing
the drain cap. Also, remove water from
drain line.
7. Before using again, clean the icemaker
and storage bin.
8. Plug in the icemaker or reconnect power.
NOTE: All components of the icemaker are
permanently lubricated at the factory. They
should not require any additional oiling
throughout the normal life of the machine.
