MULTINET SERIAL TO ETHERNET CONVERTER – INSTRUCTION MANUAL 19
11. Specifications
ETHERNET
Version 2.0/IEEE 802.3
10BaseT: ....................................................................................................RJ45 connection*
10BaseF: .....................................................................................................820 nm, multi-mode, fiber optic with
ST connector
Modbus
®
TCP/IP
NOTE
Note
* Use a shielded RJ45 cable.
RS485 PORT
RS485 2-wire, half duplex, isolated
Baud Rate: ................................................................................................300 bps to 115.2 Kbps
Protocol: .....................................................................................................Modbus
®
RTU
INSTALLATION
Configuration through EnerVista Setup software
POWER INPUT
AC power: ..................................................................................................100 to 240 V AC (±10%) at 50/60 Hz,
20 VA max
Minimum/Maximum AC voltage: 90
VAC / 264 VAC
DC power: .................................................................................................90 to 300 V DC, 5 W max.
MECHANICAL SPECIFICATIONS
Material: .....................................................................................................Metal enclosure
Dimensions: .............................................................................................6.6”  3.98”  1.46”
Shipping box: ...........................................................................................12.9”  9”  3.25”
Ship weight: .............................................................................................2 lbs.
TYPE TESTS
TEST REFERENCE STANDARD TEST LEVEL
Dielectric voltage withstand EN60255-27 2300VAC
Impulse voltage withstand EN60255-27 5KV
Insulation resistance EN60255-27 500VDC >100Mohm
Electrostatic Discharge IEC61000-4-2 Level 4
RF immunity IEC61000-4-3 20V/m 80-1GHz
Fast Transient Disturbance IEC61000-4-4 Class A and B
Surge Immunity IEC61000-4-5 2KV & 1KV
Conducted RF Immunity IEC61000-4-6 10Vrms
Radiated & Conducted Emissions CISPR11 /CISPR22/ IEC60255-25 Class A
Power magnetic Immunity IEC61000-4-8 Level 5
Pulsed Magnetic Immunity IEC61000-4-9 1000A/m
Damped Oscillatory magnetic IEC61000-4-10 100A/m
Voltage Dip & interruption IEC61000-4-11
0,40,70,80% dips, 250/
300 cycle interrupts
Damped Oscillatory IEC61000-4-18/IEEEC37.90.1 2.5KV / 1MHz
