MULTINET SERIAL TO ETHERNET CONVERTER – INSTRUCTION MANUAL 5
5. Input Power Terminals
The input power terminals are located on the left side of the green terminal block. MultiNet
may be connected to either 90 to 265 V AC at 50/60 Hz or 90 to 300 V DC supply power.
The terminals are labeled "+" and "–" for DC positive and negative input power and "L" and
"N" are for AC line and neutral input power. The GND terminal must be connected to
ground to ensure adequate protection against transients.
Control power supplied to the MultiNet must be connected to the matching power supply
range. If the voltage is applied to the wrong terminals, damage may occur!
