CAUTION: The electrical power to
the oven supply line must be shut off
while conneL_ions axe being made.
Failure to do so could result in seri-
oils injury or death.
ELECTRICALREQUIREMENTS
Thls appliance must be supplied with the proper
voltage and frequency, and connected to an individual,
properly grounded branch circuit, protected by a
circuit breaker or fuse having amperage as noted on
rating plate. (Ra_ng plate is located on oven frame.)
We recommend you have the electrical Wiling and
hookup of your oven done by a qualified electrician.
After instaliatlon, have the electrician show you where
your main range disconnect islocated.
Check with your local ui_lllties for electrical codes
which apply in your area. Failure to wire your range
according to governing codes could resultin a hazardous
condition. If there are no local codes, your range must
be wired and fused to meet the requirements of the
National Electrical Code, ANSI/NFPA No. 70-Latest
Edition. You can get a copy by wrilJxlg:
National Fire Yroteetinn Association
Battery March Park
Quincy, MA 02269
You must use a three-wire, single-phase A. C. 208Y/
120 Volt or 120/240 Volt, 60 Hertz electrical system.
If you connect to aluminum wiring, properly installed
connections approved for use with aluminum wiring
must be used.
SPECIALGROUNDINGINSTRUCTIONS
• When connecting to a 4-conductor branch circuit;
• When installing range in a mobile home;
• Whenlocal codes do not permit grounding through
nentral:
1. Cut the neutral (white) lead from the crimp, l_strlp
the neutral (white) lead to expose the proper length
of conductor.
2. Attach the appliance grounding lead (green or bare
copper) to the residence grounding conductor (green
or bare) in accordance with local codes. If the
residencegrounding conductor isaluminum, see
WARNING note below.
3. Cormect the range neutral (white) lead to the branch
circuit neutral (white or gray) in accordance with
local codes.
4. Connect the range red lead to the branch cireuit red
lead and the rm_e black lead to the branch circuit
black lead in accordance with local codes. If the
residence red and black leads are aluminum
conductors, see WARNING note below.
NOTE TO ]_LF._TRICIAN: The three power leads
suppliedwith thisapplianceare U. L.recognizedfor
connection to largergauge household wiring. The
insulation of these three leads is rated at temperatures
much higher than the temperature rating of household
wiring. The current carrying capacity of a conductor
is govexned by the temperature rating of the insulation
around the wire rather than the wire gauge alone.
ELECTRICALCONNECTION
I. De-energize range branch circuit.
2. With oven in front of cabinet opening, connect
flexible power cable to the junction box in such a
manner that it will hang down in a natural loop
against the left side of the hackwall when the oven
is installed. Do not shorten this flexlble power
cable. The flexible conduit connector must be
securely attached to the Junction box and the
flexlble conduit must be securely attached to the
connector. If the flexlble conduit wlll not fit within
the connector,-do not install the oven until a
connector of the proper size Is obtained.
• When connecting to a 3-conductor branch circuit,
ff local codes permit, connect the range bare
conductor with the crimped neutral (white) lead to
the branch circuit neutral (white or gray in color),
the range red lead to the branch circuit red lead and
the range black lead to the branch circuit black lead
in accordance with local codes.
A ARNING: Improper connection of
aluminum house wiring to :t_eso _
copper leads can result in an e_ri ;_
eal haz_l ox flxe. UR o£_,_q_aee-
tots "de'_g_-Ke_-f0r-j_d_ eopp©z._o
ainndnum_ amd-follow-_ manufac-
turer's recommended, .procedure
closely. ,'
INSTALLATION ...............
To remove the oven door: .......
1. Open the door to the stop position (see Fig. 3A).
2. Grasp the door at each side and lift up and off the
hinges {see Fig. 3B).
3
