49-80635-1
25
INSTALLATION INSTRUCTIONS
Installation Instructions
FINAL ASSEMBLY
19
INSTALL DOWNDRAFT FILTER
VENT GRILLE
Do not operate the vent without the filter in place.
• Place the filter diagonally through the vent opening.
• Make sure it rests, at an angle, on the supports in the vent
opening.
• Carefully place the vent grille onto the downdraft opening.
CHECK OPERATION OF DOWNDRAFT
• Turn the vent fan speed control to HI, MED and LO to
make sure all speeds operate correctly.
Vent Filter
Vent
Chamber
To Next Page
