7. SPECIFICATIONS
Specifications for the (B)86431-0X and B86431-4X Power Units are provided in
the following table. Unless otherwise specified, the values are the same
regardless of the option.
(B)86431-0X POWER UNIT SPECIFICATIONS
Type
Parameter
Specification
Physical
Height
89 mm (3.5 in.)
Width
29 mm (1.135 in.)
Depth
203 mm (8.0 in.)
Weight
360 g (13 oz)
Electrical
Input Range
21 - 28 VDC
(B)86431-01
Current Drain at 12 W
625 mA
(24V Station Battery)
Maximum Output
18 W
Fuse
GMT, fast-acting, 2A
Electrical
Input Range
42 - 56 VDC
(B)86431-02
Current Drain at 12 W
312 mA
(48V Station Battery)
Maximum Output
18 W
Fuse
GMT, fast-acting, 1A
Electrical
Input Range
115 - 143 VDC
(B)86431-03
Current Drain at 12 W
115 mA
(130V Station Battery)
Maximum Output
18 W
Fuse
GMT, fast-acting, 0.5A
Environmental
Operating
-20 to +60 C
(-4 to +140 ºF)
Storage
-40 to +70 C
(-40 to +158 ºF)
Relative Humidity
5 to 95 % @ 40 C
Shipping Altitude
15,000 m (50,000 ft)
Mechanical
Vibration
per MIL-STD 810E
Bench Handling
per TS 1-00446.06
EMI/RFI
Meets ANSI/IEEE
C37.90.2 RFI
Isolation
Meets ANSI/IEEE
C37.90.1 SWC
Reliability
per TR-NWT-000332
800,000 Hours
Table 2: (B)86431-0X Power Unit Specifications
