GE HEALTHCARE - KRETZTECHNIK VOLUSON® 730EXPERT (BT03)
D
IRECTION 105899, REVISION 3 DRAFT (APRIL 29, 2008) SERVICE MANUAL
9-24 Section 9-11 - Miscellaneous Cables
724
USB to ICP CPU Board
KTZ207029
Set contains two parts:
USB for PC-Slot, Connector on Backpanel.
Cables are connected to PC-Board.
Leads the USB-signals to the PC-Backpanel
(used in combination with SBC-Board KTZ208570)
2 1
USB for PC-Slot, Connector on Backpanel.
Cables are connected to PC-Board.
Leads the USB-signals to the PC-Backpanel
(used in combination with “KONTRON” SBC-Boards
KTZ209332 and/or KTZ300422)
725
USB Cable A to B
(from GEM to PC-part on GEF)
KTZ212125
USB Cable from Disk Drive Module (GEM) to connector
“USB-GEM” on the PC-part of main board module (GEF)
11
Table 9-14 Miscellaneous Cables
Item Part Name Part Number Description Qty FRU
