GE HEALTHCARE - KRETZTECHNIK VOLUSON® 730EXPERT (BT03)
D
IRECTION 105899, REVISION 3 DRAFT (APRIL 29, 2008) SERVICE MANUAL
3-46 Section 3-8 - System Configuration
3-8-4 Video Specification
Video specifications may be needed to be able to connect laser cameras or other devices to the
Voluson® 730Expert.
Table 3-13 COMP VIDEO OUT Connector
Pin No Signal Description
1 (Center Pin) Signal
2 (Coax Pin) Signal GND
Table 3-14 Footswitch Connector (located at Power Supply Module CPN - rear side)
Pin No Input Signal Description
1 Signal GND
2 right switch
normally open
3 left switch
normally open
4 not connected
not connected
Table 3-15 Video Specifications VGA Connector
Timing Parameter Value
Visible Resolution
800 x 600
Horizontal Rate [kHz]
47.20
H Total cycle time [µs]
21.20
H Sync width [µs]
1.50
H Back Porch [µs]
2.94
H Active Video Time [µs]
16.15
H Front Porch [µs]
0.616
Horizontal +/-
pos
Vertical Rate [Hz]
75.00
Vertical Total cycle time [ms]
13.30
V Sync Width [ms]
0.170
V Back Porch [ms]
0.276
V Active Video Time [ms]
12.68
V Front Porch [ms]
0.174
Dot Clock [MHz]
49.54
