Motor okay.
Check wiring harness and
motor for open
Replace motor
Check "V" belt
Check Wiring to motor
Check capacitor
Check motor winding Yellow #1 to Blue for
5.6 Ohms. Okay?
See Transmission Manual Check section
line voltage at
Does basket
spin?
Motor okay
Motor hums
Check for line voltage at PCB
terminal (Yellow #1 to Red and
Yellow #1 to Blue)
Lift Red and Blue terminal from PCB. Check
resistance. Check yellow #1 to Red for 5.6 Ohms.
Check yellow #1 to Blue for 5.6 Ohms.
C
)
