GE Zoneline Generation-3 2800 Series User Manual

– 13 –
2800 Series
Running Current Cooling- With unit in case and room front installed, operated for 10 minutes on HI-COOL.
Temperature Differential Cooling - Unit must operate for one hour with thermostat at coldest setting prior
to measuring air temperatures.
7000 BTUH Units 9000 BTUH Units 12000 BTUH Units 15000 BTUH Units
Current/Temperature Check Data - Cooling Current in Amps
Air Temp
Condenser In
230V
Min Max
2 0 8 V
Min Max
230V
Min Max
2 0 8 V
Min Max
230V
Min Max
2 0 8 V
Min Max
2 3 0 V
Min Max
2 0 8 V
Min Max
80°F 2.3 2.8 2.4 2.9 3.1 3.6 3.2 3.7 3.8 4.3 4.0 4.5 4.8 5.3 5.2 5.7
95°F 2.7 3.2 2.8 3.3 3.5 4.0 3.8 4.3 4.4 4.9 4.7 5.2 6.2 6.7 6.8 7.3
110°F 3.2 3.7 3.4 3.9 4.5 5.0 4.8 5.3 5.4 5.9 5.8 6.3 7.7 8.2 8.5 9.0
Temperature Differential Check Data - Evaporator Air Temp Out in °F
Evaporator
Air Temp In
230V
Min Max
2 0 8 V
Min Max
230V
Min Max
2 0 8 V
Min Max
230V
Min Max
2 0 8 V
Min Max
230V
Min Max
2 0 8 V
Min Max
70°F 45 50 44 49 40 44 39 43 42 46 41 45 39 43 37 41
80°F 55 60 53 58 57 61 56 60 53 57 53 57 48 52 46 50
90°F 61 66 62 67 64 68 63 67 59 63 61 65 56 61 54 59
230/208 VAC, 2800 Series Models
265 VAC, 2800 Series Models
7000 BTUH Units 9000 BTUH Units 12000 BTUH Units 15000 BTUH Units
Current/Temperature Check Data - Cooling Current in Amps
Air Temp
Condenser In
265V
Min Max
265V Min
Max
265V
Min Max
265V
Min Max
80°F 2.0 2.5 2.7 3.2 3.3 3.8 4.2 4.6
95°F 2.3 2.8 3.1 3.6 3.8 4.3 5.4 5.9
110°F 2.8 3.3 3.9 4.4 4.7 5.2 6.6 7.1
Temperature Differential Check Data - Evaporator Air Temp Out °F
Evaporator
Air Temp In
265V
Min Max
265V
Min Max
265V
Min Max
265V
Min Max
70°F 45 50 40 45 42 46 39 43
80°F 55 60 57 62 53 57 48 52
90°F 61 66 64 69 59 63 56 61
