– 14 –
3800 Series
Running Current Cooling - With unit in case and room front installed, operated for 10 minutes on HI-COOL.
Running Current Heating - With unit in case and room front installed, operated for 10 minutes on HI-HEAT.
Temperature Differential Cooling - Unit must operate for one hour with thermostat at coldest setting prior
to measuring air temperatures.
Temperature Differential Heating - Unit must operate for one hour in reverse cycle heating thermostat at
prior to measuring air temperatures.
7000 BTUH Units 9000 BTUH Units 12000 BTUH Units 15000 BTUH Units
Current/Temperature Check Data
Air Temp
Condenser In
Cooling Current in Amps
230V
Min Max
208 V
Min Max
230V
Min Max
2 08V
Min Max
230V
Min Max
208V
Min Max
2 30V
Min Max
2 08 V
Min Max
80°F 2.3 2.8 2.4 2.9 3.1 3.6 3.2 3.7 3.8 4.3 4.0 4.5 4.8 5.3 5.2 5.7
95°F 2.7 3.2 2.8 3.3 3.5 4.0 3.8 4.3 4.4 4.9 4.7 5.2 6.2 6.7 6.8 7.3
110°F 3.2 3.7 3.4 3.9 4.5 5.0 4.8 5.3 5.4 5.9 5.8 6.3 7.7 8.2 8.5 9.0
Air Temp
Outdoor
Coil In
Reverse Cycle Heating Current in Amps
230V
Min Max
208 V
Min Max
230V
Min Max
2 08V
Min Max
230V
Min Max
208V
Min Max
230V
Min Max
2 08 V
Min Max
47°F 2.3 2.8 2.5 3.0 2.9 3.4 3.1 3.6 4.1 4.6 4.3 4.8 5.7 6.2 6.2 6.7
60°F 2.5 3.0 2.7 3.2 3.0 3.5 3.2 3.7 4.2 4.7 4.6 5.1 6.3 6.8 7.0 7.5
75°F 2.7 3.2 3.1 3.6 3.3 3.8 3.7 4.2 4.8 5.3 5.4 5.9 6.9 7.4 7.9 8.4
Temperature Differential Check Data
Evaporator
Air Temp In
Evaporator Air Temp Out °F
230V
Min Max
208 V
Min Max
230V
Min Max
2 08V
Min Max
230V
Min Max
208V
Min Max
230V
Min Max
2 08 V
Min Max
70°F 45 50 44 49 40 44 39 43 42 46 41 45 39 43 37 41
80°F 55 60 53 58 57 61 56 60 53 57 53 57 48 52 46 50
90°F 61 66 62 67 64 68 63 67 59 63 61 65 56 61 54 59
Indoor Air
Temp In
Indoor Coil Air Temp Out °F
230V
Min Max
208 V
Min Max
230V
Min Max
2 08V
Min Max
230V
Min Max
208V
Min Max
230V
Min Max
2 08 V
Min Max
70°F 93 98 95 100 90 94 92 96 100 105 100 105 113 118 116 121
75°F 103 108 103 108 98 102 99 103 109 114 113 118 122 127 127 132
80°F 111 116 113 118 105 109 107 111 117 122 124 129 134 139 138 143
230/208 VAC, 3800 Series Models
