GE Zoneline User Manual

13
geappliances.com
Complete Accessory List
Kit Number Description For Additional Information Refer to Pages
RAK3152 Line cord power connection kit - 230/208 V - 2.61/2.19 kW - 15 amp 11 & 12
RAK3202 Line cord power connection kit - 230/208 V - 3.42/2.87 kW - 20 amp 11 & 12
RAK3302 Line cord power connection kit - 230/208 V - 4.81/4.07 kW - 30 amp 11 & 12
RAK4157 Direct connect power connection kit - 230/208 V - 2.61/2.19 kW - 15 amp 11 & 12
RAK4207 Direct connect power connection kit - 230/208 V - 3.42/2.87 kW - 20 amp 11 & 12
RAK4307 Direct connect power connection kit - 230/208 V - 4.81/4.07 kW - 30 amp 11 & 12
RAK5157 Direct connect power connection kit - 265 volt - 2.71 kW - 15 amp 11 & 12
RAK5207 Direct connect power connection kit - 265 volt - 3.55 kW - 20 amp 11 & 12
RAK5307 Direct connect power connection kit - 265 volt - 5.03 kW - 30 amp 11 & 12
RAK148D1 Digital thermostat for heat pump - single stage cool - two stage heat 11 & 12
RAK148P1 Digital programmable t’stat for heat pump - single stage cool - two stage heat 11 & 12
RAK164D1 Digital t’stat for resistance heat unit - single stage cool - single stage heat 11 & 12
RAK164P1 Digital programmable t’stat - resistance heat unit- single stage cool - single stage heat 11 & 12
RAVAL1 Exterior grille 10 & 15
RAVRG1 Access panel for return air 11 & 15
RAVRMS Freeze Sentinel
™
/temperature limiting room air sensor 6 & 12
RAVRG2 Return Air Grille for flush door 11 & 15
RAVWP6 Wall Plenum for walls up to 6" thick 10 & 15
RAVWP8 Wall Plenum for walls up to 8" thick 10 & 15
RAVWP12 Wall Plenum for walls up to 12" thick 10 & 15
RAVWP15 Wall Plenum for walls up to 15" thick 10 & 15
RAVHW1 Hydronic kit, single row heat; exchanger - 9k and 12k models only 14
RAVHW2 Hydronic kit, double row heat; exchanger - 9k, 12k and 18k models only 14
RAVHW3 Hydronic kit, triple row heat; exchanger - 12k and 18k models only 14
Unit Specifications
AZ85E09DAC AZ85E12DAC AZ85E18DAC AZ85H09DAC AZ85H12DAC AZ85H18DAC
230/208 Volt Models Electric resistance heat Heat pumps
Features
BTUH 9,000/8,800 11,700/11,500 17,9 0 0/ 17,70 0 8,800/8,600 11,700/11,500 17, 8 0 0/17, 70 0
Watts 860/840 1105/1090 1870/1850 840/820 1105/1090 1860/1850
E.E.R. 10.5/10.5 10.6/10.6 9.3/9.3 10.5/10.5 10.6/10.6 9.3/9.3
Cool Amps 4.1/4.4 5.2/5.7 8.9/9.8 4.1/4.4 5.2/5.7 8.9/9.8
Dehumidification
(pints/hr.) 2.5 3.2 5.0 2.5 3.2 5.0
SHR
0.81 0.79 0.71 0.83 0.79 0.69
Reverse Cycle (BTUH) N/A N/A N/A 8,200/8,000 10,400/10,300 16,400/16,200
COP @ 47° N/A N/A N/A 3.4/3.4 3.4/3.4 3.0/3.0
Indoor CFM (Hi/Med/Lo) 520/460/360 590/500/380 600/520/400 520/460/360 590/500/380 600/520/400
Unit Width (in.) 23 -1/8 23 -1/8 23 -1/8 23-1 /8 23-1/8 23 -1/8
Unit Depth (in.) 23-1/8 23-1/8 23-1/8 23-1/8 23-1/8 23-1/8
Unit Height (in.) 32-1 /4 32-1 /4 32-1 /4 32-1 /4 32-1 /4 32-1 /4
Ship Wt. 159 161 178 162 165 179
Net Wt. 146 148 165 149 152 166
AZ85E09EAC AZ85E12EAC AZ85E18EAC AZ85H09EAC AZ85H12EAC AZ85H18EAC
265 Volt Models Electric resistant heat Heat pumps
Features
BTUH 9,000 11,700 17,9 0 0 8,800 11,700 17,800
Watts 860 1105 1870 840 1105 1860
E.E.R. 10.5 10.6 9.3 10.5 10.6 9.3
Cool Amps 3.5 4.5 7. 8 3.5 4.5 7. 8
Dehumidification
(pints/hr.) 2.5 3.2 5.0 2.5 3.2 5.0
SHR 0.82 0.80 0.70 0.83 0.79 0.70
Reverse Cycle (BTUH) N/A N/A N/A 8,200 10,400 16,400
COP @ 47° N/A N/A N/A 3.4 3.4 3.0
Indoor CFM (Hi/Med/Lo) 520/460/360 590/500/380 600/520/400 520/460/360 590/500/380 600/520/400
Unit Width (in.) 23 -1/8 23 -1/8 23 -1/8 23-1 /8 23-1/8 23 -1/8
Unit Depth (in.) 23-1/8 23-1/8 23-1/8 23-1/8 23-1/8 23-1/8
Unit Height (in.) 32-1 /4 32-1 /4 32-1 /4 32-1 /4 32-1 /4 32-1 /4
Ship Wt. 159 161 178 162 165 179
Net Wt. 146 148 165 149 152 166
265 Volt available by special order only.
