GE Zoneline User Manual

15
geappliances.com
REQUIREDACCESSORIES
(Check the “Essential Elements” label on the unit.)
Architectural Louver
RAVAL1
Wall Plenum
RAVWP6 - 6"D x 19-3/4"W x 32"H
RAVWP8 - 8"D x 19-3/4"W x 32"H
RAVWP12 - 12"D x 19-3/4"W x 32"H
RAVWP15 - 15"D x 19-3/4"W x 32"H
Access Panel with
Return Air Grille
RAVRG1
Return Air Grille
RAVRG2
OR
Wall Thermostat
Model Type Mechanical Thermostat Electronic Thermostat
Heat/Cool/Hydronic Models 4-wire 5-wire
Heat Pump Models 6-wire 6-wire
Check the thermostat instructions for correct wiring and installation requirements.
30"
50"
22-1/2"
22-1/2"
Cutout
Dimensions:
28"W x 48"H
Cutout
Dimensions:
20"W x 32-1/4"H
Cutout
Dimensions:
20-3/8"W x 20-3/8"H
Required Accessories
Wall Thermostat
Model Type Electronic Thermostat
Heat/Cool/Hydronic Models 5-wire
Heat Pump Models 6-wire
Check the thermostat instructions for correct wiring and
installation requirements.
Components of the Zoneline
®
System
(Check the “Essential Elements” label on the unit.)
