9 | Dimensions and connections
SV
DV
Suction line
Discharge line
see technical data, Chapter 8
A
Connection suction side, not lockable
7
/
16
“ UNF
A1
Connection suction side, lockable
7
/
16
“ UNF
A2
Connection suction side, not lockable
1
/
8
“ NPTF
B
Connection discharge side, not lockable
7
/
16
“ UNF
B1
Connection discharge side, lockable
7
/
16
“ UNF
C
Connection oil pressure safety switch OIL
1
/
8
“ NPTF
D
Connection oil pressure safety switch LP
1
/
4
“ NPTF
E
Connection oil pressure gauge
1
/
8
“ NPTF
F
Oil drain M22 x 1,5
G
Opt. connection for oil sump heating
1)
M22 x 1,5
H
Oil charge plug
1
/
4
“ NPTF
K
Sightglass 1
1
/
8
“- 18 UNEF
L
Connection thermal protection thermostat
1
/
8
“ NPTF
M
Oil strainer M22 x 1,5
SV1
Opt. connection for suction line valve --
1)
= Only possible ex factory
