• HG44e:Semi-hermeticfour-cylinderreciprocatingcompressorwithsuction-gascooleddrivemotor.

• HG56e:Semi-hermeticsix-cylinderreciprocatingcompressorwithsuction-gascooleddrivemotor.

• Preferredapplicationrange:normalrefrigeratingandair-conditioning.

3| Product description

Nameplate

Fig.1

3.1 Short description

Valveplate

Cylinder

cover

DimensionandconnectionvaluescanbefoundinChapter 12

Transporteyelet

Discharge

shut-offvalve

Oilpump

Suction

shut-offvalve

Oilsightglass

Drivesection

Motorsection

Fig.2

HG44e

HG56e

Terminal

box
