Grasso
Refri
eration Division
GRASSO SYSTEM CONTROL
01.2004/1 638660E_chapter1.doc Chap. 1 - 11
Disch temp
Tdis hi alarm
High warning -
Disch temp.: Actual discharge temperature in °C
Tdis hi alarm: Alarm limit for maximum discharge temperature in °C
High warning: Enter the warning value as an offset to the alarm value
<< Limit values 01 >> in K
Tdis hi alarm
High limit -
Incr limit -
Tdis hi alarm: Alarm limit for maximum discharge temperature in °C
High limit: Begin of the discharge temperature limitation -
enter value as an offset to the alarm value in K
<< Limit values 01 >> Incr limit: Begin of the forced increasment of the capacity due to
high discharge temperature -
enter value as an offset to the alarm value in K
Oil dif press
dPoil low alarm
Low warning +
Oil dif press.: Actual oil differential pressure in bar
dPoil low alarm: Alarm limit for minimum pressure differential in bar
Low warning: Enter the warning value as an offset to the alarm value
<< Limit values 01 >> in bar
Oil temp
Toil low alarm
Low warning -
Oil temp: Actual oil temperature in °C
Toil low alarm: Alarm limit for minimum oil temperature in °C
Low warning: Enter the warning value as an offset to the alarm value
<< Limit values 01 >> in K
Oil temp
Low limit
Oil press °C/R
Oil temp: Actual oil temperature in °C
Low limit: Begin of the start limitation due to low oil temperature -
enter value as an offset to the actual value in °C
<< Limit values 01 >> Oil press °C/R: Actual oil pressure in °C
Oil temp
Toil hi alarm
High warning -
Oil temp: Actual oil temperature in °C
Toil hi alarm: Alarm limit for maximum oil temperature in °C
High warning: Enter the warning value as an offset to the alarm value
<< Limit values 01 >> in K
Motor current
Imot hi alarm
High warning -
Motor current: Actual motor current in A
Imot hi alarm: Alarm limit for maximum motor current in A
Warning: Enter the warning value as an offset to the alarm value
<< Limit values 01 >> in A
