GRASSO SYSTEM CONTROL
Chap. 1 - 12 638660E_chapter1.doc 01.2004/1
Imot hi alarm 
High limit - 
Decr factor - 
Imot hi alarm: Alarm limit for maximum current in A
High limit: Begin of the motor current limitation -
enter value as an offset to the alarm value in A
<< Limit values 01 >> Decr factor: Begin of the forced decreasment of the capacity due to
high motor current -
A value of 0% disables this function / 100% equals a lineair
relation between motor current and compressor capacity
External temp 
Text low alarm 
Low warning + 
External temp.: Actual external temperature in °C
Text low alarm: Alarm limit for minimum external temperature in °C
Low warning: Enter the warning value as an offset to the alarm value
<< Limit values 01 >> in K
Text low alarm 
Low limit + 
Decr limit + 
Text low alarm: Alarm limit for minimum external temperature in °C
Low limit: Begin of the temperature limitation -
enter value as an offset to the alarm value in K
<< Limit values 01 >> Decr limit: Begin of the forced decreasment of the capacity due to
low external temperature -
enter value as an offset to the alarm value in K
Motor speed 
Nmot low alarm 
Low warning - 
Motor speed: Actual motor speed in rpm
Nmot low alarm: Alarm limit for minimum motor speed in rpm
Low warning: Enter the warning value as an offset to the alarm value
<< Limit values 01 in rpm
Motor speed 
Nmot hi alarm 
High warning - 
Motor speed: Actual motor speed in rpm
Nmot hi alarm: Alarm limit for maximum motor speed in rpm
High warning: Enter the warning value as an offset to the alarm value
<< Limit values 01 >> in rpm
Capacity  %
Minimum  %
Maximum  %
Capacity: Actual capacity step (for the low pressure stage) in %
Minimum: Minimum capacity below the auxiliary output is enabled
when “Min cap” selected in %
<< Limit values 01 Maximum: Maximum capacity above the auxiliary output is enabled
when “Max cap” selected in %
