Pause secs Pause time between pulses.

Auto stop position %

As soon as the control slide has reached this value or is below this

value the "Auto stop delay" will start (stand alone operation). In

sequence operation the control slide is stopped at this position and

the compressor is allowed to stop if it is allowed by the sequence

module.

fig.1: Hysteresis, Neutral Zone

Process value

SP Setpoint

NZ Neutral zone

HYS Hysteresis

A Time characteristic of process value

B Time characteristic of the 3-step-controller outputs

C Time characteristic of the pulse generator

D Time character of the pulsed outputs to the capacity control solenoid valves

Parameters Operating Manual | Sequence Control for Packages

GSC TP

10 GEA Refrigeration Germany GmbH | E_301510_2 | Generated 17.12.2014
