Operating status
Signal tone sounds six
times and red LED flashes
Red LED lights up and
signal tone sounds six
times
Pressing tool stops and no
LED lights up
Operating instructions ACO 201
Cause
Stop button was
pressed or pressing tool
was not in starting
position
Pressing tool is
overloaded. The
pressing systems
processed were not
approved
Pressing tool is faulty
Accumulator is faulty
After the pressing operation
Operating status Cause
Green LED flashes Accumulator is not
charged up sufficiently
for a further pressing
operation
Maintenance schedule
Actions
• Press stop button
• Press start button: Roller drive moves to its
starting position
• Repeat the pressing operation
• Press stop button
• Press start button
• Only use permitted pressing systems, see Use
• Repeat the pressing operation
• Press stop button
• Press start button
• If this is not successful, take the pressing tool
to a service centre for checking
• Have the accumulator checked and renew it if
necessary
• Press start button
• Press stop button
• Press start button again: Roller drive moves to
its starting position
• Repeat the pressing operation
Actions
Charge the accumulator or renew it
An inspection sticker on the pressing tool indicates the date when the
next service is due. The pressing tool must always be sent in for
maintenance together with the pressing jaws and the battery charger
in its transport case.
For information about authorised specialist workshops, please
contact your responsible Geberit sales company directly or visit
www.geberit.com.
Interval Maintenance work
Regularly • Check the pressing tool and accumulator for externally visible defects
and damage that could affect safety
• Clean and lubricate the pressing tool
• Clean and lubricate pressing jaws/adapters and pressing collars/
MapressMAM jaw adapters: see operating instructions of the particular
system
B310-001&BDC © 02-2006
20
