Operation
Inserting the Geberit pressing jaw or Geberit adapter jaw
Prerequisites
Pressing tool is de-energised.
1 Remove the retaining pin (see cover page in the front, figure A).
2 Insert the pressing jaw or adapter jaw in the pressing tool (see cover page in the front,
figure B).
3 Push the retaining pin in until the stop position is reached (see cover page in the front,
figure C).
Charging and inserting the Geberit rechargeable battery
1 Charge the rechargeable battery before commissioning.
2 Insert the rechargeable battery into the pressing tool from below (see cover page in
the front, figure D).
Result
Pressing tool is in sleep mode. No LED lights up.
WARNING
Danger of crushing by exposed parts
` Do not hold any parts of your body or other objects in between the pressing jaws
` Keep your fingers away from the roller range if there is no pressing jaw inserted
CAUTION
Damage to the device because the retaining pin is not pushed in completely
` Push the retaining pin in completely
CAUTION
Damage to the device due to incorrect rechargeable battery
` Make sure that the voltage of the rechargeable battery corresponds to the details
on the specification plate of the pressing tool
Read the user manual for the battery charger for information on how the battery
charger functions.
Remove the rechargeable battery from the pressing tool before transporting and
storing it; otherwise the rechargeable battery will run flat.
