Geberit ACO 203 - Pressing with Geberit pressing attachments

EN
ATTENTION
Damage to the device due to incorrect
rechargeable battery
▶ Make sure that only suitable Geberit
lithium-ion batteries of type
Milwaukee18V are used.
5 Slide the rechargeable battery into
the pressing tool from below until the
battery fastens into place.
Result
✓ Pressing tool is in idle state. No LED is
lit.
Pressing with Geberit
pressing attachments
WARNING
Risk of injury caused by flying
fragments
▶ Wear protective goggles and a
protective helmet.
WARNING
Risk of injury caused by the use
of incorrect pressing
attachments
▶ Only use pressing
attachments that correspond
to the diameter of the press-
fittings to be processed.
WARNING
Risk of fire from heat build-up
▶ Allow the pressing tool to cool
down for at least 30minutes
after 30minutes of continuous
operation.
▶ Do not place or store the hot
pressing tool near easily
flammable materials.
The pressing procedure can be
cancelled at any time. → See
"Cancelling the pressing procedure".
Prerequisite
– Pipe ends are deburred and clean.
– The pipe section and pressfitting are
fitted together according to the
installation manual of the piping system.
– The pressing attachment is inserted
correctly.
1 In order to activate the tool from idle
state, tap the start button.
✓ The tool is ready for operation;
the green LED lights up.
30
