Gecko in.k1000+ User Manual

6
1
+
4°
Installation of in.k1000+
Installation
Gasket with or without adhesive
Optional wing nuts
and spacers
To install the in�k1000+, use the drilling template provided in this section�
Determine the mounting location and stick the template on the chosen location�
Cut out an opening according to the template (see illustration)�
Clean the installation surface and peel the adhesive gasket from the back
of the keypad�
Insert the keypad and align it correctly, then ensure it is properly glued
by gently pressing evenly on the entire surface�
When installing the keypad on the spa, a minimum angle of 4 degrees must be respected�

Gecko in.k1000+ Specifications

General

Brand	Gecko
Model	in.k1000+
Category	Touch Panel
Language	English
