16
Specifications
Environmental ratings
Operating temperature: -5 °C (23 °F) to 43 °C (109 °F)
Water resistance: IPX4
Mechanical CE models NA* models
Compressor: Rotary (GMCC) Rotary (GMCC)
Pressure: Min: 1,5 MPa (218 psi) Min: 1,5 MPa (218 psi)
Max: 4,15 MPa (609 psi) Max: 4,15 MPa (602 psi)
5kW 7,5kW 5kW 7,5kW
Refrigerant: R32/650g (22,9oz) R32/800g (28,2oz) R410A/800g (28,2oz) R410A/1100g (38,8oz)
Weight:
Net: 39 kg (86 lbs) 45 kg (99 lbs) 39 kg (86 lbs) 45 kg (99 lbs)
Gross: 45 kg (99 lbs) 48 kg (106 lbs) 45 kg (99 lbs) 48 kg (106 lbs)
Carton box size: 850 x 390 x 572 mm 960 x 408 x 670 mm 793 x 360 x 555 mm 960 x 408 x 670 mm
33,5 x 15,4 x 22,5 in 37,8 x 16,1 x 26,4 in 31,2 x 14,2 x 21,9 in 37,8 x 16,1 x 26,4 in
Best efficiency flow rate: 2,35 M³/h (10 GPM) 3,3 M³/h (15 GPM) 2,35 M³/h (10 GPM) 3,3 M³/h (15 GPM)
Flow detector: Flow switch Flow switch
Noise at 1 m: 54dB(A) 62dB(A) 54dB(A) 62dB(A)
Electrical CE models NA* models
Input Supply: 220 V ~ 240 V, 50 Hz 240 V ± 5%, 60 Hz
5kW 7,5kW 5kW 7,5kW
Power input (max): 1,29 kW 1,91 kW 1,6 kW 2,3 kW
Rated Current
1
: 3,9 A 5,49 A 5,27 A 6,32 A
Max Current
1
: 6,07 A 8,67 A 7,5 A 9,6 A
Communication Supply: 10-12 Vdc, 80mA 10-12 Vdc, 80mA
Performances CE models NA* models
5kW 7,5kW 5kW 7,5kW
Heating capacity
2
: 5,54 kW 7,52 kW 5,34 kW 7,6 kW
Power input: 0,89 kW 1,23 kW 1,14 kW 1,36 kW
COP: 6,21 6,13 4,7 5,69
Heating capacity
3
: 3,99 kW 5,63 kW 4,06 kW 5,92 kW
Power input: 0,87 kW 1,26 kW 1,08 kW 1,36 kW
COP: 4,59 4,48 3,76 4,36
Cooling Capacity
4
: 3,87 kW 6,24 kW 3,73 kW 6,16 kW
Power input: 1,2 kW 1,66 kW 1,37 kW 1,72 kW
EER: 3,21 3,76 2,7 3,58
Compatibility
in.temp is compatible with all in.ye and in.yt versions equipped with a RS-485 interface.
in.temp requires software core 61 revision 54 or higher to operate.
1
Wires gauge and breaker size should be dimensioned according to the maximum current rating.
2
Based on the following operating conditions: 24°C (75°F) Ambient air, 26°C (79°F) Water inlet.
3
Based on the following operating conditions: 15°C (59°F) Ambient air, 26°C (79°F) Water inlet.
4
Based on the following operating conditions: 35°C (95°F) Ambient air, 29°C (84°F) Water inlet.
*North American
