Technical Data
The device can be ordered with different technical specifications:
Prozessor: Intel® ATOM™ N270, 1.6 GHz
Chipset: Intel® 945GSE, 533 MHz FSB
DRAM: DDR2 533 SODIMM up to 2048 MB
Cache: 512K 2
nd
Level
Video: Intel Intel® GMA950, Supports DX 9.0c
Resolution: Explorer 15i 1024x768, 262 kB/16 Mio. colors
Explorer 18i, 1280x1024, 16 Mio. colors
Ethernet: 10/100Base-T Intel® 82562V,
IEEE 802.3
Serial Ex i 2x 16550 compatibel (RXD, TXD, RTS, CTS)
Serial Ex e 1x 16550 compatibel (RXD, TXD)
USB: 4x USB Ex i, 1x USB Ex e
Mass storage: 64 GB SSD up to 4x CF Cards (8 GB / 16 GB)
Optional:
Sound: AC97 controller, Intel 945GSE, line in/out, Mic
RS485 Ex e: Half Duplex 2-wire RS485, up to 115.2K, auto TX enable,R
Line
=120Ω
RS422 Ex e: 4-wire (default) or auto TX, up to 115.2K
The manufacturer reserves the right to change technical data without notice in order to
enhance the performance and take advantage of technical advances.
Zone 1
Zone 21
International ignition protection:
II 2G Ex e mb [ia] IIC T4 II 2D Ex tD A21 IP6X T120°C
Operating temperature:
(Certified range)
(10 to 90% rel. humidity, n. c.)
Ta: -20°C ... +50°C
(-4°F to 122°F)
Ta: -20°C ... +50°C
(-4°F to 122°F)
Certificate:
IBExU 05 ATEX 1186 X
IBExU 05 ATEX 1186 X
Recommended operating temperature: 0…+45 °C, 10 to 90% rel. huminity, n. condens.
High ambient temperature will reduce the lifespan of the LCD display.
Low ambient temperatures could affect the picture quality.
Housing material: Steel / Aluminum / Stainless Steel
Housing dimensions: refer to drawings attached
Weight : Explorer 15i appr. 20kg (appr. 44lb)
Explorer 18i appr. 25kg (appr. 55lb)
Ingress Protection Encl.: Front IP66 / NEMA 4X when mounted correctly.
Storage temperature: -20 °C - +60°C (-4°F to 140°F), 10 to 90% rel. humidity, n. cond.
