Terminal Connections
Supply circuit X50
Connection
Significance
100-240V AC 24V DC
X50-1
Supplycircuit
L
Supplycircuit
+24V DC
X50-2
Outputcircuit
L
Outputcircuit
+24V DC
X50-3
Supplycircuit
N
Supplycircuit
0V DC
X50-4
Outputcircuit
N
Outputcircuit
0V DC
The devices are supplied via the Supply circuit. The Output circuit are integrated to
supply optional other devices. The Supply circuit and the Output circuit are connected
parallel.
Serial Interface (RS232 or RS485 or RS422) X51
Connection
Significance
RS232
RS485
RS422
X51-1
GND
485-
RX-
X51-2
RXD
485+
RX+
X51-3
TXD
GND
TX-
X51-4
TX+
USB Interface X52
Connection
Significance
Signal
Prefered color
X52-1
+UB
rd
X52-2
D-
wh
X52-3 D+ gn
X52-4
GND
bk
Ethernet 10/100 Interface X53
Connection
Significance
Signal
Preferred
colour
Preferred
colour CH
X53-1
(1) TX+
wh/or
bk
X53-2
(2) TX-
or
gn
X53-3
(3) RX+
wh/gn
rd
X53-4
(4)
bl
wh
X53-5
(5)
wh/bl
bl
X53-6
(6) RX-
gn
or
X53-7
(7)
wh/br
ye
X53-8
(8)
br
br
X53-9
Shield
Shield
Shield
