Keyboard Interface X33
Connection
Significance
X33-1
Data
X33-3
GND
X33-4
+UB
X33-5
Clock
Cable Screen
GND
Mouse Interface X34
Connection
Significance
X34-1
Data
X34-3
GND
X34-4
+UB
X34-5
Clock
Cable Screen
GND
USB1i Interface X35
Connection
Significance
X35-1
+UB
X35-2
D-
X35-3
D+
X35-4
GND
Cable Screen
GND
USB2i Interface X36
Connection
Significance
X36-1
+UB
X36-2
D-
X36-3
D+
X36-4
GND
Cable Screen
GND
USB3i Interface X37
Connection
Significance
X37-1
+UB
X37-2
D-
X37-3 D+
X37-4
GND
Cable Screen
GND
USB4i Interface X38
Connection
Significance
X38-1
+UB
X38-2
D-
X38-3
D+
X38-4
GND
Cable Screen
GND
