GECMA EXPLORER 15i - Page 15

Manual Explorer 15i 18i 2nd rev2.2 en Gecma Components electronic GmbH
GEC17500221 csckerpen@eaton.com
+49 2273 9812 0 15
COM1i RS232 Interface X39
Connection
Significance
X39-2
RXD
X39-3
TXD
X39-5
GND
X39-7
RTS
X39-8
CTS
Cable Screen
GND
COM2i RS232 Interface X40
Connection
Significance
X40-2
RXD
X40-3
TXD
X40-5
GND
X40-7
RTS
X40-8
CTS
Cable Screen
GND
Audio Line out Interface X42
Connection
Significance
X42-1
GND
X42-2
Line out R
X42-3
Line out L
Audio Line in Interface X43
Connection
Significance
X43-1
GND
X43-2
Line in R
X43-3
Line in L
Audio Mic Interface X44
Connection
Significance
X44-1
GND
X44-2
MIC Bias
X44-3
Mic
Ext. 12V Interface X45 (standard)
Connection
Significance
X45-2
GND
X45-3
GND
X45-4
12V DC
