19
Fig
ure 1Figure 2Figure 3
e.
When charging is complete, the user has to wait until the status indicator lights up and first unplug the
charging gun from the end of the vehicle and then unplug the charging plug from the household socket.
f.
Cover the charger gun dust cover on the vehicle and close the charging cover. Then place the charger in
the special storage box.
B.
Charging procedure using the public AC charging stack (using the American standard charging
gun as an example):
Caution:
Before using the public charging stack, please ensure that the public charging stack provides an AC
charging service with 230V.
If the vehicle battery is the lead-acid battery, please select the 16 A-.
Charging range for charging. If the vehicle battery is a lithium battery, please select the 32 A
charging range for charging.
