Gefen EXT-CU-LAN Setup Guide

Installation & Conguration
1. Connect all Gefen Video over IP units to an approved / compatible managed switch.
Refer to the User Manual(s) for the Gefen Video over IP units to obtain the network
requirements.
2. Connect a shielded CAT-5e (or better) Ethernet cable from the LAN 1 port on the
Matrix Controller to the same network where the Gefen Video over IP units are
connected.
EXT-CU-LAN
to Gefen
KVM over IP
Devices
Managed
Switch
Router
LAN
POE
5V DC
1 2
Matrix Controller
Status
IR
Power
Menu
1 2 3
4 5 6
7 8 9
In 0 Out Set
Clear
Mask
Preset
Back
OK
Lock
®
Setup Guide
LAN 1 port
page | 1
