Appendix
Specications
Supported Formats
Resolutions (max.) • 1920 x 1200 (WUXGA)
• 3840 x 2400 (WQUXGA)
Electrical
Maximum Pixel Clock • 2 x 165 MHz
Input Video Signal • 1.2V p-p
Input DDC signal • 5V p-p (TTL)
Power Indicator • 1 x LED, blue
Link Indicators • 2 x LED, green
Connectors
Video Input • 1 x DVI-D, 29-pin, female
Video Outputs • 2 x DVI-D, 29-pin, female
Operational
Power Input • 1 x 5V DC
Power Consumption • 5W (max.)
Operating Temperature • +32 to +104 °F (0 to +40 °C)
Physical
Dimensions (W x H x D) • 4” x 3.25” x 1.25”
(102mm x 83mm x 32mm)
Unit Weight • 0.2 lbs (0.09 kg)
