7
RECEIVER UNIT DESCRIPTIONS
1 Brightness Trim
Use a small-head Phillips screwdriver to adjust the brightness level of the
picture.
2 RJ-45
Connect the CAT-5e cable from the Sender unit to this RJ-45 jack.
3 Power Indicator
This LED indicator will glow bright red when the
4 VGA In
Connect a VGA / component source to this HD-15 connector.
5 DIP Switches (not shown)
The bottom of the Receiver unit has three banks of four DIP switches on the
bottom of the unit. Remove the piece of tape to expose the DIP switches.
See page 9 for more information on using the DIP switches.
