IInn PP.. 33
Setting Input 3
This menu lets you configure parameters for the input 3 signals.
Probe type, signal, enable custom
linearization, and main input scale
Input 3 Digital Filter
[0.00 ... 20.00] sec
If set to “0” the average filter is excluded on the sampled
value
Decimal Point Position for Scale
Input 3
Size
0 xxxxx
1 xxxx.x
2 xxx.xx
3 xx.xxx
4 x.xxxx
MIN Scale Limit Input 3
Min...Max value assigned to input selected with
parameter TYP3
MAX Scale Limit Input 3
Offset Correction Input 3
[-999 ... +999] scale points
Probe type Scale limits
0 Input disabled
1 0...10V
-19999/99999
2 0...20mA -19999/99999
3 4...20mA -19999/99999
4 potentiometer -19999/99999
+32 enable custom linearization
PV
tyP.3
PV
InP.3
PV
F1t.3
PV
dPS.3
PV
LoS.3
PV
x1S.3
PV
0FS.3
+8 disables the Lo and x1 messages
N.B.:
the scale limits can be reversed
