OUT 1
Attribute reference signal
00 vv tt
Setting Outputs
This menu lets you configure the output parameters.
Function
0 OFF
1 AL1 – alarm 1
2 AL2 – alarm 2
3 AL3 – alarm 3
5 Repeat logic input 1
6 Repeat logic input 2
7 Repeat but 1 key
8 AL1 or AL2
9 AL1 or AL2 or AL3
10 AL1 And AL2
11 AL1 and AL2 and AL3
16 or AL3 ... AL10
17 and AL3 ... AL10
18 AL 4 – alarm 4
19 AL4 or AL5
20 AL4 or AL5 or AL6
21 AL4 or AL5 or AL6 or AL7
22 AL4 and AL5
23 AL4 and AL5 and AL6
24 AL4 and AL5 and AL6 and AL7
25 AL8 or AL9
26 AL8 or AL9 or AL10
27 AL8 and AL9
28 AL8 and AL9 and AL10
Add +32 to the values indicated in the table to obtain the denied
logic level in output, or reverse for CO1, CO2.
OUT 2
Attribute reference signal
OUT 3 (*)
Attribute reference signal
OUT 4 (*)
Attribute reference signal
(*) available only without MD8 expansion
The 8 outputs available by means of the MD8
expansion assume the state of alarms
AL3,...,AL10
OUT W Retransmission Output Type
0 Output disabled
1 0...10V
2 2...10V
3 0...20mA
4 4...20mA
5 ±10V
Reference quantity
0 IN1
1 IN2
2 IN3
3 IN4
4 Fin.A (math function A)
5 Fin.b (math function b)
12 Value acquired from serial line
13 Input 1 maximum peak
14 Input 1 minimum peak
15 Input 1 peak-peak
16 Input 2 maximum peak
17 Input 2 minimum peak
18 Input 2 peak-peak
19 AL1 (limit)
20 AL2 (limit)
21 AL3 (limit)
Attribute reference signal OUT W
+8 reverse output
MIN analog repeat output scale
[reference variable scale range]
MAX analog repeat output scale
[reference variable scale range]
Select probe power supply
0 2,5V for potentiometers
1 5V for strain gauge
2 10V for strain gauge
max. 200mA
RL.1
+32 only for riF.An = 0,1,2,3,4,5: output at max/min hard-
ware (beyond calibration limits) for input at Hi/Lo
+64 only for riF.An = 0,1,2,3,4,5: output at minimum if
input is in Err, Sbr, Ebr condition
