Math function B
0 Function disabled
1 Fin.b = ( ((C1.B * In1.B)^ C2.B) OPEr.B ((C3.B * In2.B)^ C4.B)) / C5.B
2 IN1 + IN2
3 IN1 - IN2
4 IN1 / IN2 [IN2 only with positive scale (1...99999)]
5 Square root IN1 [IN1 only with positive scale (0...99999)]
6 (IN1 + IN2)/ 2
7 IN3 * C1.B
8 (IN1 + IN2 + IN3 + IN4) / 4
if Func.b = 1
C
B
[xrd]
PV
(5.b
PV
(4.b
PV
(3.b
PV
(2.b
PV
(1.b
PV
0PEr.b
PV
In2.b
PV
In1.b
PV
Fvnc.b
First operand
Second operand
0= 0
1 IN1
2 IN2
3 IN3
4 IN4
5 Fin.A
Mathematical Operator B
Coefficient C1.b
[-9.99 ... 99.99]
Coefficient C2.b
Coefficient C3.b
[-9.99 ... 99.99]
Coefficient C4.b
Coefficient C5.b
[-9.99 ... 99.99]
0+
1-
2*
3/
0= 1
1 = 1/2
2= 2
0= 1
1 = 1/2
2= 2
